Description
The VMAX Remote Multideck Open Chiller 1250mm is an open-front remote refrigeration multideck cabinet built for retailers who want to maximise product accessibility and shopper engagement across a chilled display run. At 1250mm wide with a 1,015L net volume and 2.19m² total display area (calculated to EN ISO 23953), it delivers a fully open, continuously accessible chilled merchandise display — with all refrigeration equipment housed remotely in a machine room or external plant. The open-front format removes the barrier between shopper and product entirely, driving faster pick rates on high-velocity chilled lines such as dairy, fresh produce, deli and chilled drinks.
Why Choose the 1250mm Open Multideck?
The 1250mm open remote multideck is the most compact bay in the VMAX open range — a focused chilled display unit that puts products within immediate reach of every shopper who passes. With a 1,015L net volume and 2.19m² total display area, it suits standalone impulse positions — beside a checkout, at a café counter or at the entrance to a chilled aisle — where maximum product accessibility matters. The open-front format increases pick rates compared to glass door alternatives, making it particularly effective for high-velocity lines such as chilled snacks, dairy, grab-and-go and fresh produce.
Key Features
- 1,015L net volume / 2.19m² TDA – measured to EN ISO 23953, Part 2, Annex A (5 shelves at 400mm)
- Open-front design – no doors; full, unrestricted shopper access at all times
- Remote refrigeration – direct expansion evaporator cabinet; connects to remote condensing unit via 9.52/15.88mm connections
- Off-cycle defrost – 6 cycles per 24h; 30-min maximum duration, 3-min drip time
- Evaporator fans – 2 × 13W for powerful, even air curtain across the open front
- Dual-zone LED lighting – roof (2 × 13W) and shelf-level (5 × 13W) for direct product illumination
- 5 adjustable shelves – 400mm depth, white; shelf loading to EN ISO 23953 standard
- Electronic thermostat – air-off probe; thermostat ON +5°C / OFF +3°C
- Climate Class 3 – rated for 25°C ambient / 60% RH operating environments
- End-walls not included – available separately to finish standalone installations or multi-bay runs
Technical Specifications
| Net Volume | 1,015L |
| Total Display Area (TDA) | 2.19 m² |
| Footprint | 0.95 m² |
| Temperature Range | -1°C to +7°C |
| Cooling Type | Remote (direct expansion evaporator) |
| Climate Class | 3 (25°C, 60% RH) |
| Defrost Type | Off-cycle, 6×/24h |
| Refrigeration Power Required | 1,936W |
| Cabinet Connections (in/out) | 9.52 / 15.88 mm |
| Evaporator Fan Motors | 2 × 13W |
| Roof Lighting | 2 × 13W LED |
| Shelf Lighting | 5 × 13W LED |
| Fan Electrical Load | 26W |
| Lighting Electrical Load | 95W |
| Voltage / Frequency | 220–240V / 50Hz |
| Noise Level | ≤60 dB(A) |
| Thermostat Set Points | ON +5°C / OFF +3°C |
| Alarm Set Point | -5°C to +15°C |
| Weight (excl. end-walls) | 120 kg |
| Shelves | 5 × white, 400mm depth |
Dimensions
Length (excl. end-walls)
1250mm
Height
2200mm
Depth
760mm
Weight (excl. end-walls)
120 kg
This unit is a remote refrigeration cabinet and does not include a condensing unit or compressor. It requires connection to a separate remote condensing unit by a qualified refrigeration engineer. Please contact our team for advice on compatible plant room equipment.
Speak to Our Commercial Refrigeration Team
Remote multideck installations require careful planning — bay count, plant room sizing, refrigerant circuit design. Our team can advise on the full specification before you order, with trade prices and fast UK delivery as standard.
